SP Series Robots

SP Series robots are 4-axis robots with simple structure, low failure rate. This model has many advantages such as easy to operate, saving energy, with less area occupation etc. Large payload capability enables the robot to handle materials easily which is suitable for heavy loading and large-scale working environment.

Availability:


Inquire

Features
Specifications
Application
Download

· Large working space

· Stable performance

· High running speed

· Highly optimized for general use

· Modular mechanical structure design

SP Series Robots

GUESS YOU LIKE

Industrial Robot

SR Series Robots

SA Series Robots

SD Series Robots

SCARA Robot AR series

Model		SP120
Wrist Rated Payload		120kg
Max Working Radius		2403mm
DOF		4
Max Speed	J1	145° /s
	J2	110° /s
	J3	120° /s
	J4	300° /s
Max Operation Area	J1	±165°
	J2	85°~ -40°
	J3	65°~ -65°
	J4	±360°
	J2 ＋J3	﹢120°~-20°
Wrist Allowable Torque	J4	250 Nm
Wrist Allowable Inertia	J4	70 kg㎡
Weight		1040kg
Position Repeat Accuracy		±0.2mm
Ambient Temperature		0~40℃

Model		SP200
Wrist Rated Payload		200kg
Max Working Radius		3003mm
DOF		4
Max Speed	J1	120° /s
	J2	120° /s
	J3	120° /s
	J4	300° /s
Max Operation Area	J1	±180°
	J2	75°~ -40°
	J3	60°~ -50°
	J4	±360°
	J2 ＋J3	﹢112°~-20°
Wrist Allowable Torque	J4	480 Nm
Wrist Allowable Inertia	J4	70 kg㎡
Weight		1820kg
Position Repeat Accuracy		±0.5mm
Ambient Temperature		0~40℃

Model		SP120
Wrist Rated Payload		120kg
Max Working Radius		2403mm
DOF		4
Max Speed	J1	145° /s
	J2	110° /s
	J3	120° /s
	J4	300° /s
Max Operation Area	J1	±165°
	J2	85°~ -40°
	J3	65°~ -65°
	J4	±360°
	J2 ＋J3	﹢120°~-20°
Wrist Allowable Torque	J4	250 Nm
Wrist Allowable Inertia	J4	70 kg㎡
Weight		1040kg
Position Repeat Accuracy		±0.2mm
Ambient Temperature		0~40℃

Model		SP200
Wrist Rated Payload		200kg
Max Working Radius		3003mm
DOF		4
Max Speed	J1	120° /s
	J2	120° /s
	J3	120° /s
	J4	300° /s
Max Operation Area	J1	±180°
	J2	75°~ -40°
	J3	60°~ -50°
	J4	±360°
	J2 ＋J3	﹢112°~-20°
Wrist Allowable Torque	J4	480 Nm
Wrist Allowable Inertia	J4	70 kg㎡
Weight		1820kg
Position Repeat Accuracy		±0.5mm
Ambient Temperature		0~40℃
